BrandStand CubieBlue Charging Alarm Clock
Product Features
- Combination Bluetooth Speaker, Power & Alarm
- Bluetooth Music Play Through
- User-friendly alarm clock with single-day alarm (optional)
- Convenient connections for AC and USB-powered devices
- Display Dimmer – 3 Levels and OFF
- Auto-Update for Daylight Saving Time
- Surge protection through all AC outlets and/or USB Ports
Product Description
- Bluetooth Speaker
- 2 Tamper-Resistant 125V AC outlets
- 1 USB-A port
- 1 USB-C port
- Single Day Alarm Clock
- Surge Protection
- 6ft 14AWG Power Cord with Right Angle Pass Through Plug
- Security C-Clamp with 2 Wood Screw
Technical Specifications
- Continuous Duty Electrical Rating
125VAC 12A 60Hz 1500W - Maximum Energy Dissipation
615J L-N 205J L-G 205J N-G 205J - Maximum Spike Current
24000A L-N 8000A L-G 8000A N-G 8000A - UL Clamping Voltage (3-line)
UL1449
VPR L-N 1200V, L-G 1200V, N-G 1200V - AC Outlets Output
125V 12A - EMI/RFI Filtration
150kHz-1000MHz up to 40db - Surge Response Time (ns)
<20 ns - Working Temperature
0-35º C - Power Cord
6ft 14AWG 3-line - Housing Material
UL94V-0 - Working Surroundings
Indoor Fixed Mount
Powered USB Output
- SINGLE USB-C OUTPUT(20W MAX ):5V 3A or 9V 2.22A or 12V 1.67A
- SINGLE USB-A OUTPUT(18W MAX):5V 3A or 9V 2.A or 12V 1.5A
- DOUBLE PORT USB-C+USB-A OUTPUT(15W MAX):5V 3A
Important Safeguards
- CAUTION: Do not install this device if there is not at least 10 meters (30feet) or more of wirebetween the electrical outlet and the electrical service panel. Ensure the unit is plugged into an AC 120V-60Hz outlet. The use of incorrect outlets could cause the unit to malfunction or catch fire.
- To reduce the risk of fire or electrical shock, do not use this device with a receptacle in which the slot openings do not align with the blades.
- Do not allow children to operate the unit without adult supervision.
- Always ensure the product is unplugged from the electrical outlet before relocating or cleaning it.
- Keep the power cord and product away from heated surfaces.
- The unit should not be exposed to dripping or splashing and no objects filled with liquids, such as vases should be placed on or around the product. It should not be used with aquariums or other water-related products.
- Do not place or drop the product into water or other liquids. If the product falls into water, immediately unplug it from the electrical outlet.
- Do not put any stress on the power cord where it connects to the product, as the power cord could fray and break.
- Do not plug/unplug the product into/from the electrical outlet with a wet hand.
- Do not operate the product if it has a damaged or cut power cord or adapter, if wires are exposed, if it malfunctions, if it is dropped or damaged, or if it is dropped in or exposed to water.
- Place the unit where there is good air circulation.
- The product has no user-serviceable parts. Do not attempt to examine or repair this product yourself. Only qualified service personnel should perform the servicing.
- No open flame sources, such as candles, should be placed on the product.
- The product should only be used indoors and in dry locations.
Limited 1-Year Warranty
Products are warranted by Brandstand against manufacturing defects in material and workmanship under normal use for one year from the date of purchase. Defective products will be exchanged for the same or a comparable item.
Return Policy
For a refund or exchange, products must be returned within 30 days of original purchase date. Customers must contact Brandstand to obtain a Return Merchandise Authorization (RMA) number and specific shipping instructions prior to returning the product. Any product returned without a RMA will be refused. Product must be in original box with original accessories and packaging undamaged, clean and brand-new condition.
Products that are incomplete, damaged, or have been used will require a deduction from the refund. There is a 30% restocking fee on all returned products. Refunds will be issued by check. Refund checks are mailed on the 10th day from the date the product is returned. Delivery charges and customized products are non-returnable.
Disclaimer of Damages
In no event shall Brandstand Products, or its suppliers, be liable for indirect, incidental, or consequential damages, loss of profit, loss of use or data, or interruption of business, whether the alleged damages are labeled in tort, contract, or indemnity, even if Brandstand Products or its suppliers has been advised of the possibility of such damages. Some states do not allow the exclusion or limitation of incidental or consequential damages, so the above limitation may not apply.
Important:
This product’s USB outlets cannot be used as a USB hub and do not transmit data. The powered USB outlets on this unit are intended solely for charging devices that can be charged via a USB interface.
Battery Handling and Usage
WARNING: Only adults should handle batteries. Do not allow a child to use this product unless the Battery Compartment Cover is securely attached to the Battery Compartment under all product usage instructions.
- Follow the battery manufacturer’s safety and usage instructions.
- Keep batteries away from children and pets.
- Do not mix a new and a used battery or mix batteries of different chemistries or sizes.
- Insert the batteries observing the proper polarity (+/-) as indicated inside the battery compartment. Failure to properly align the battery polarity can cause personal injury and/or property damage.
- Remove spent or discharged batteries when not using the product for an extended period.
- Never throw batteries into a fire. Do not expose batteries to fire or other heat sources.
- Dispose of or recycle spent/discharged batteries in compliance with all applicable laws. For detailed information, contact your local solid waste authority.
The Brandstand Difference
ETL Tested to UL Standards
- Complies with IEC 62368-1 (Audio/Video, Information and Communication Technology Equipment) and includes safety testing for Surge Protection.
- Complies with UL 962A (Furniture Power Distribution Units) and includes Liquid Spill Testing. For enhanced safety, the Cubie Product Line was designed for and successfully passed a UL spill test conducted by our ETL testing lab.
Pass-Through Power
The pass-through power plug allows another device (i.e. lamp or alarm clock) to be plugged into the same wall outlet used by the Cubie Product.
Unpacking and Set up
- Carefully remove from packaging. Verify that you have all necessary components before you dispose of the box and packaging.
Component List:- CubieBlue Main Unit
- Security C-Clamp
- 2 Wood Screws
- Place in the desired location.
Note: This product is designed to be used on a level, stable, flat surface such as a table, desk,shelf or stand, convenient to an AC outlet, out of direct sunlight and awat from sources of excess heat, dust, moisture or vibration. - Plug directly into a wall AC outlet. Do not plug into another surge protector or extension cord.
- Secure the cord with a Security C-Clamp to the back of the nightstand or desk. Wood screws are included.
Setting the Time
- Press and hold the SNOOZE/DIMMER button for 6 seconds.
- Year will begin to flash, adjust by rotating knob, press knob to select.
- Month will begin to flash, adjust by rotating knob, press knob to select.
- Day will begin to flash, adjust by rotating knob, press knob to select.
- Time will begin to flash, adjust by rotating knob, press knob to select.
Setting the Alarm
- Press knob to turn ON alarm.
- Alarm time will begin to flash, adjust by rotating knob, press knob to select. (Alarm will automatically set to the last selected alarm time after 6 seconds.)
- Press knob to turn OFF alarm.
Bluetooth Pairing
- Open the Bluetooth settings on your device
- Press the CubieBlue Bluetooth button.
- The Bluetooth button flashes, and CubieBlue becomes discoverable
- Connect your device to CubieBlue and enjoy your music
Volume Control
- Rotate knob to adjust the volume.
Secure Battery Door/Hidden Switches
Single Day Alarm (Preset to ON)
- ON: Alarm time will reset to 6:00 am with every activation of the alarm
- OFF: The alarm time will default back to the last set alarm time with every activation.
Daylight Saving Time (Preset to ON)
- ON: Time will automatically update +1 or -1 hour based on the pre-set Daylight Saving Time Calendar. Year, Month and Day must be set correctly for this feature to work properly.
- OFF: Time will not automatically update for Daylight Saving Time. Any changes to the time must be manually updated.
Back Up Battery Function
Two “AAA” Batteries are supplied with the clock. If the AC power supply is interrupted, the internal clock will not be interrupted due to battery back up. Please note – The back up battery will not support the Alarm Settings.
Other Features
Snooze/Dimmer Button
When in standby mode, press SNOOZE/DIMMER button to change brightness (off, dimmest, medium, brightest). When the display is turned off, user can also press and rotate the wheel to turn display ON.
When an alarm is sounding, press the SNOOZE/DIMMER button to go to snooze status, the alarm symbol will flash and the alarm will resound after 9 minutes.
Gradual Wake
The alarm will sound in a low volume and gradually increase to a higher volume.
Brandstand
1219 Digital Drive, Suite 100 Richardson, TX 75081, USA
877-843-3681
www.brandstand.com
