IMPORTANT

• Record the serial number from the tag on the back of the safe or from the tag on the front bottom corner of the safe.
• Keep keys and combination in a secure place away from children. Do not store trouble key or this document in the safe.
• Do not move this safe using its handle. The handle should only be used for opening and closing the door of the safe.
• Removing the back panel on the door will void the fire rating.

INSTALLATION OF SCOPE STAND-OFF

• NOTE: The scope stand-off will function properly for many combinations of guns with scopes. Screw the scope stand-off into the pilot hole of the barrel rest. (Figure 1)

HANDLE ASSEMBLY

• Screw the 5 handle spokes into the hub and hand tighten. (Figure 2). These spokes are located in the front foam packaging.
• NOTE: Do not use this handle to move the safe

SELECTING A LOCATION

• Your safe should be installed in an isolated, dry and secure area. For extra humidity control we recommend the use of a desiccant. Do not drill holes in the safe for electrical dehumidifying devices. Do not drill through the insulation in the rear vent holes. Do not mount the safe to a wall using these vent hole. This will void the fire rating. For greater security the safe should be located in a corner and fastened to the floor. (Figure 3)

SECURING THE SAFE

• IMPORTANT: Because this safe is waterproof it will float. As the water level rises, the safe will begin to float and could fall over causing personal injury.
• The safe must be fastened to the floor using the lag bolts and gasket washer provided with this safe to insure the waterproof rating. Failure to do so will void the waterprooof rating. You must remove the safe from the skid and place the safe on the floor. Failure to do so will void the fire and waterproof ratings.
• Place the safe in the desired location. Lift the carpeting up and locate the mounting hole bushings. These bushings are filled with fire resistant caulking which must be drilled out before mounting the safe to the floor. Use a 3/8″ diameter drill bit to drill out this caulking. Continue to use this drill to mark the hole location on the floor. Move the safe away. Drill pilot holes in the floor as follows:
• For a wood floor drill 5/16″ diameter x 2-1/2″ deep pilot holes. For a masonry floor drill 7/16″ diameter x 2-1/2″ deep pilot holes for the anchors.
• IMPORTANT: When you drill out the fire resistant caulking from the mounting hole bushings you must mount the safe to the floor using the lag bolts and gasket washers. Failure to do so will void the fire rating and waterproof rating. Reposition the safe and secure the safe with the lag bolts and gasket washers. (Figure 4) Replace the carpeting.

MODELS WITH OPTIONAL SHELVING

• The shelving can be installed by locating the shelf clips to the desired locations and setting the shelf in place
• Do not store electronic media, computer disks, audio-visual media or photographic negatives in this safe. This material will not survive the rated internal temperature of the safe. This material may be damaged or destroyed

ELECTRONIC LOCK

• You must first install the battery which is located in the front protective styrofoam (See BATTERY REPLACEMANT below)
• To open an electronic lock the first time, press the following numbers/symbols on the electronic keypad in this order: 1, 5, 9, #. (These numbers are preset. You should change the entry code as soon as possible after opening the safe to insure proper security). After you have entered the factory code, you will need to turn the handle clockwise to open the door. You will have 5 seconds to turn the handle before the locking mechanism is reactivated.

ENTERING YOUR SECURITY CODE

DO NOT SHUT THE DOOR UNTIL YOU HAVE CONFIRMED THAT YOUR NEW SECURITY CODE HAS BEEN ENTERED CORRECTLY. To enter your own security code you will need to follow the steps listed below:

1. After opening the electronic safe (with the preset factory code of 1, 5, 9, #) locate the small red red button on the inside of the door near the hinge.
2. Press the red button and then release it, you will hear a beep. The yellow light on the faceplate will be activated and will stay on for a period of time that should allow you to enter your code. You can only enter your code while the yellow light is on. With the door open and the yellow light on, enter your own personal security code, which can be 3 – 8 digits long, and confirm your new code by pressing the ” Star” symbol on the electronic touch pad. Before you close the door, try the new security code to make sure the lock releases the handle so you can turn it and retract the live action bolts.
   • DO NOT SHUT THE DOOR UNTIL YOU HAVE CONFIRMED THAT YOUR NEW SECURITY CODE HAS BEEN ENTERED CORRECTLY.
   • If the code fails, go through steps 1 and 2 again. If the code works successfully record your combination number on the front of this form or somewhere in your records, then you should lock the safe.
   • When you open the safe in the future enter the security code you have set followed by the “ # ” symbol. If the incorrect security code is entered 3 times you will have an automatic lockout for 20 seconds before you can try your code again.
   • If the incorrect security code is entered 3 additional times there will be a 5-minute lockout before the code can be tried again.

TURNING THE KEYPAD SOUND OFF/ON

• You can turn off the “Beep” sound of the keypad by entering the code 633.
• To turn the “Beep” sound on, enter the code Star 66.

BATTERY REPLACEMENT

• NOTE: When changing the battery, always hold the battery connecting cap while disconnecting or attaching the battery. Do not pull on the wires. Doing this could cause the power supply to become disconnected from the lock. This lock includes a memory chip so the combination you have programmed into the lock will not be lost when changing the battery.
• This safe uses one 9V alkaline battery. Under normal use, batteries will last about 1 year. When the battery is low and you press a button on the keypad, a red light will come on warning you that the battery is low. To test the batteries, enter your security code. If the batteries are low the red light will come on momentarily. To replace the battery, remove the cover by pressing the tab and turning the cover as shown in the illustration. Replace the old battery and screw the cover back in place.

TROUBLE KEY

A “Trouble Key” has been provided in case you have forgotten or lost your security code. To open the safe using the trouble key follow the steps below:

1. Remove the cover by pressing the tab and turning the cover as shown in the illustration. The lock can hang by the connecting cable while unlocking the safe.
2. Insert the key in the key hole and turn clockwise 1/4 turn (until stopped) in order to unlock the safe. Rotate the handle and open the door.
3. Keep the door open until you have entered a new security code. Before entering your new code, remove the key and screw the cover back in place.
4. Enter your new security code following the instructions at the top of the page
   • NOTE: The Manufacturer, retailer, and brand license owner are not responsible for any cost incurred if the safe is damaged due to a flood.
   • IMPORTANT
   • Keep keys and combination number in a secure place, away from children. Keep this record of your key number and combination in a secure place separate from your safe. To order a replacement key set, follow the instructions on the attached form
