KLIM Chroma Wireless RGB Gaming Keyboard User Manual

KLIM Chroma Wireless RGB Gaming Keyboard

Keyboard Specifications

• Model: KLIM Chroma Wireless
• Wireless frequency bond: 2.4 Ghz
• Wireless distance: up to 10 m
• Mini Receiver: Plug and Ploy
• Battery capacity: 1300 mAh
• Charging time: 4 hours
• Continuous usage time at max brightness: 17 hours Voltage: 3.7V
• Key life expectancy: 10 million keystrokes
• Waterproof rating: IP03
• Internal noise reduction system for silent keystrokes Multimedia shortcuts: via FN key
• Light effects: static lighting/ breathing mode/ off
• Lighting options: effect speed/ brightness adjustment Energy saving
• sleep mode: ofter 60 seconds
• Power switch: under the keyboard
• Keyboard size: 440 x 149 x 22 mm
• Gaming-grade: Anti-Ghosting

Weight

• Keyboard weight: 480 g
• USB coble: 25 g
• Receiver: 2 g
• Total weight (with battery): 680 g
• Supported Operating Systems: Windows XP /Vista/ 7 / 8 / 10, Moc□S, Linux

Troubleshooting

1. Check if the receiver is properly connected to the computer and that the bottom switch of the keyboard is turned ON.
2. Try connecting the receiver to another USB port on your computer.
3. Try rebooting your computer.
4. If it still does not work, try connecting the keyboard to another computer.

Indicator icon

1. Num Lock light
2. Cops Lock Light
3. Charging status indicator

Charging status Indication: When the USB is connected, the blue charging indicator light indicates charge mode. The light will turn off when charging is complete.

1. 3 lighting effects, Fn+:  static, breathing, off.
2. Fn+ Effect speed adjustment, Fn+ brightness adjustment.

THE FUNCTION KEYS

• Fn+Fl =Media Player
• Fn+F2=Volume­
• Fn+F3=Volume+
• Fn+F4=Mute
• Fn+F5=Stop
• Fn+F6=Previous track
• Fn+F7=Play /Pause
• Fn+F8=Next track
• Fn+F9=Email
• Fn+Fl =Web/Home
