Razer Huntsman Mini Gaming Keyboard User Manual

Razer Huntsman Mini Gaming Keyboard

WHAT’S INSIDE

• Razer Huntsman Mini
• A. Volume control keys
• B. Media keys
• C. On-The-Fly macro record key
• D. Gaming mode key
• E. Backlight control keys
• F. Sleep mode key
• G. Kickstand
• H. Type C por
• Detachable Type C to Type A cable
• Important Product Information Guide

WHAT’S NEEDED

PRODUCT REQUIREMENTS

• PC with a free USB port

RAZER SYNAPSE 3 REQUIREMENTS

• Windows® 7 64-bit (or higher)
• Internet connection for software installation

LET’S GET YOU COVERED

• You’ve got a great device in your hands, complete with a 2-year limited warranty coverage. Now maximize its potential and score exclusive Razer benefits by registering at razerid.razer.com
• Got a question? Ask the Razer Sunnort Team at support.razer.com

TECHNICAL SPECIFICATIONS

• Razer™ Linear Optical Switch with 40 G actuation force
• 100 million keystroke lifespan
• Razer Doubleshot PBT Keycaps
• Standard Bottom Row Layout
• Aluminum construction
• 60% Compact form factor
• Detachable USB-C Braided Fiber Cable
• Hybrid onboard storage – up to 5 keybinding profiles
• Onboard lighting presets
• Individually backlit keys with Razer Chroma RGB backlighting featuring 16.8 million customizable color options
• Razer Synapse 3 enabled
• Fully programmable keys with on-the-fly macro recording
• N-key roll-over with built-in anti-ghosting
• Gaming mode option
• 1000 Hz Ultrapolling

SETTING UP YOUR HUNTSMAN MINI

1. Connect the keyboard to your computer using the detachable Type C to Type A cable.
2. 2. Use the Razer Synapse* app to customize its lighting and even create various profiles suited for different playstyles. Up to 5 of these profiles can be stored on your keyboard from the Razer Synapse app, allowing you to use these profiles even on systems without the app installed.
   • © Install Razer Synapse when prompted or download the installer from razer.com/synapse

USING YOUR RAZER HUNTSMAN MINI

When the “fn” key is held down, all function keys with secondary functions including other keys that you can combine with the “fn” key will light up. Pressing the “fn” key in combination with the function keys will activate their secondary features on your PC

ON-THE-FLY MACRO RECORDING (PC)

Follow these steps to create an OTF Macro Recording

1. Press the key combination to start recording.
2. The Macro Recording Indicator will light up to show that the device is ready to record.
3. Type in the keys you want to record.
4. Press the key combination to stop the recording or the ESC key to cancel the recording. The Macro Recording Indicator will start blinking to show that the device has stopped recording and is ready to save the macro.
5. Press the desired key where you want to save your macro

GAMING MODE (PC)

• The Gaming Mode disables the Windows Key function to avoid accidental usage. Furthermore, you can maximize the effect of Anti-Ghosting by activating the Gaming Mode function. You can also choose to disable the Alt + Tab and Alt + F4 functions by changing the Gaming Mode settings in Razer Synapse 3. An indicator will light up when Gaming Mode is active

CONFIGURING YOUR RAZER HUNTSMAN MINI

Disclaimer: The features listed here require you to log into Razer Synapse 3. These features are also subject to change based on the current software version and your Operating System.

SYNAPSE TAB

• The Synapse tab is your default tab when you first launch Razer Synapse 3

Dashboard

• The Dashboard subtab is an overview of your Razer Synapse 3 where you can access all your Razer devices, modules, and online services

Modules

The Modules subtab displays all installed and available modules for installation.

Global Shortcuts

• Bind operations or Razer Synapse functions to custom key combinations from any Razer Synapse-enabled device inputs which apply across all device profiles.
• Only Razer Synapse-enabled device inputs will be recognized.

KEYBOARD

• The Keyboard tab is the main tab for your Razer Huntsman Mini. From here, you can change your device settings such as key assignments, gaming mode settings, and your device’s lighting. Changes made under this tab are automatically saved to your system and cloud storage

Customize

• The Customize subtab is for modifying your keyboard’s key assignments and gaming mode Profile settings.

Profile

• Profile is a data storage for keeping all your Razer peripheral’s settings. By default, the profile name is based on your system’s name. To add, import, rename, duplicate, export, or delete a profile, simply press the profile’s corresponding Miscellaneous button (•••)

Hypershift

• Hypershift mode is a secondary set of key assignments that is activated when the Hypershift key is held down. By default, the Hypershift key is assigned to the fn key of your Razer Synapse 3-supported keyboard however, you can also assign any key as a Hypershift key

Gaming Mode

• Gaming Mode enables you to customize which keys to disable when Gaming Mode is activated. Depending on your settings, you may choose to disable the Windows key, Alt + Tab, and Alt + F4

Keyboard Properties

• Allows you to open the Windows Keyboard Properties where you can modify other keyboard settings such as Repeat delay, Repeat Rate, and Cursor blink rate, or view all keyboard drivers installed in your PC

Sidebar

• Clicking the Sidebar button () will reveal all current key assignments for your Razer Huntsman Mini

Alternatively, you can skip to a specific key assignment by selecting it on the Customize tab.
Upon selecting a key assignment, you may then change it to one of the following functions:

• Default
• This option enables you to return the selected key to its original setting.
• Keyboard Function
• This option changes the key assignment into a keyboard function. You can also choose enable Turbo mode which allows you to emulate repeatedly pressing the keyboard function while the key is held down.
• Mouse Function
• This option allows you to change any key into a mouse function. Listed below are the functions which you can choose from:
• Left Click – Performs a left mouse click using the assigned button.
• Right Click – Performs a right mouse click using the assigned button.
• Scroll Click – Activates the universal scrolling function.
• Double Click – Performs a double left click using the assigned button
• Mouse Button 4 – Performs a “Backward” command for most internet browsers.
• Mouse Button 5 – Performs a “Forward” command for most internet browsers.
• Scroll Up – Performs a “Scroll Up” command using the assigned button.
• Scroll Down – Performs a “Scroll Down” command using the assigned button.
• Scroll Left – Performs a “Scroll Left” command using the assigned button.
• Scroll Right – Performs a “Scroll Right” command using the assigned button.
  You can also choose to enable Turbo mode in some of the mouse functions which allow you to emulate repeatedly pressing and releasing said function while the key is held down.
• Macro
• A Macro is a prerecorded sequence of keystrokes and button presses that is executed with precise timing. By setting the key function to Macro, you can conveniently execute a chain of commands. Do take note that this function will only be visible if you have installed the Macro module from the Modules tab. Click here to learn more about Macros
• Switch Profile
• Switch Profile enables you to quickly change profiles and load a new set of key assignments. An on-screen notification will appear whenever you switch profiles.
• Switch Lighting
• Switch Lighting allows you to easily switch between all advanced lighting effects. Do take note that this function will only be visible if you have installed the Chroma module from the Modules tab. Click here to learn more about Advanced Chroma Effects
• Razer Hypershift
  Setting the key to Razer Hypershift will allow you to activate Hypershift mode as long as the key is held down.
• Launch Program
• Launch Program enables you to open an app or a website using the assigned key. When you select Launch Program, twochoices will appear which requires you to search for a specific app you want to open, or write the address of the website you want to visit.
• Multimedia
  This option allows you to assign multimedia controls to your Razer device. Listed below are the multimedia controls you can choose from:
  • Volume Down- Decreases the audio output.
  • Volume Up – Increases the audio output.
  • Mute Volume – Mutes the audio.
  • Mic Volume Up – Increases the microphone volume.
  • Mic Volume Down – Decreases the microphone volume.
  • Mute Mic – Mutes the microphone.
  • Mute All – Mutes both microphone and audio output.
  • Play / Pause – Play, pause, or resume playback of the current media.
  • Previous Track – Play the previous media track.
  • Next Track – Play the next media track
• Windows Shortcuts
• This option allows you to assign your preferred key into a Windows Operating System shortcut command. For more information, please visit: support.microsoft.com/kb/126449
• Text Function
• Text Function enables you to type a prewritten text with a touch of a key. Simply write your desired text on the given field and your text will be typed whenever the assigned key is pressed. This function has full Unicode support and vou can also insert special symbols from character men.
• Disable
• This option renders the assigned key unusable. Use Disable if you do not want to use the selected key or if it interferes with your gaming

Lighting

• The Lighting subtab enables you to modify your Razer device’s light settings

Brightness

• You can turn off your Razer device’s lighting by toggling the Brightness option or increase/decrease the luminance using the slider.
• Switch Off Lighting
• This is a power saving tool that allows you to disable your device’s lighting in response to your system’s display turns off and/or automatically power down when your Razer Huntsman Mini has been idle for a set amount of time.
• Quick Effects
• A number of quick effects can be selected and applied to your device’s lighting as listed here:
  • Only devices that support the selected lighting effect will synchronize. LED indicators are not customizable.
• If you have other supported Razer Chroma-enabled devices, you can synchronize their quick effects with your Razer device by clicking the Chroma Sync button(()
• Studio Effects
• The Studio Effects option allows you to choose a Chroma Effect you want to use on your Razer Chroma-enabled peripheral. To start making your own Chroma Effect, simply press the Chroma Studio button (). Click here to learn more about the Chroma Studio

PROFILES TAB

• The Profiles tab is a convenient way of managing all your profiles and linking them to your games and applications.

Devices

• View which games are linked to each device’s profiles or which Chroma Effect is linked to specific games using the Devices subtab.
• You can import Profiles / Chroma Effects from your computer or from the cloud through the import button (), or create new profiles within the selected device or new Chroma Effects for specific games using the add button ( ). To rename, duplicate, export, or delete a profile, simply press the Miscellaneous button (). Each profile and/or Chroma Effect can be set to automatically activate when you run an application using the Linked Games option.

Linked Games

• The Linked Games subtab gives you the flexibility to add games, view peripherals that are linked to games, or search for added games. You can also sort games based on alphabetical order, last played, or most played. Added games will still be listed here even if it is not linked to a Razer device.
• To link games to connected Razer devices or Chroma Effects, simply click on any game from the list, and then click Select a device and its profile to launch automatically during gameplay to select the Razer device or Chroma Effect it will link with.
• Once linked, you may click on the Miscellaneous button () of the corresponding Chroma Effect or device to select a specific Chroma Effect or profile.

SETTINGS WINDOW

• The Settings window, accessible by clicking the () button on Razer Synapse 3, enables you to configure the startup behavior and display language of Razer Synapse 3, view the master guides of each connected Razer device, or perform factory reset on
•  provides relevant links for its terms of use. You may also use this tab to check for software updates, or as a quick access to Razer’s social communities.

SAFETY AND MAINTENANCE

SAFETY GUIDELINES

In order to achieve maximum safety while using your Razer Huntsman Mini, we suggest that you adopt the following guidelines:

• Should you have trouble operating the device properly and troubleshooting does not work, unplug the device and contact the Razer hotline or go to support.razer.com for support.
• Do not take apart the device (doing so will void your warranty) and do not attempt to operate it under abnormal current loads.
• Keep the device away from liquid, humidity or moisture. Operate the device only within the specific temperature range of 0°C (32° F) to 40°C (104°F). Should the temperature exceed this range, unplug and/or switch off the device in order to let the temperature stabilize to an optimal level

COMFORT

Research has shown that long periods of repetitive motion, improper positioning of your computer peripherals, incorrect body position, and poor habits may be associated with physical discomfort and injury to nerves, tendons, and muscles. Below are some guidelines to avoid injury and ensure optimum comfort while using your Razer Huntsman Mini.

1. Position your keyboard and monitor directly in front of you with your mouse next to it. Place your elbows next to your side, not too far away and your keyboard within easy reach.
2. Adjust the height of your chair and table so that the keyboard and mouse are at or below elbow height.
3. Keep your feet well supported, posture straight and your shoulders relaxed.
4. During gameplay, relax your wrist and keep it straight. If you do the same tasks with your hands repeatedly, try not to bend, extend or twist your hands for long periods.
5. Do not rest your wrists on hard surfaces for long periods.
6. Use a wrist rest to support your wrist while gaming.
7. Customize the keys on your keyboard to suit your style of gaming in order to minimize repetitive or awkward motions while gaming-
8. Do not sit in the same position all day. Get up, step away from your desk, and do exercises to stretch your arms. shoulders. neck and legs.If you should experience any physical discomfort while using your keyboard, such as pain, numbness, or tingling in your hands, wrists, elbows, shoulders, neck or back, please consult a qualified medical doctor immediately.

MAINTENANCE AND USE

• The Razer Huntsman Mini requires minimum maintenance to keep it in optimum condition. Once a month we recommend you unplug the device from the computer and clean it using a soft cloth or cotton swab to prevent dirt buildup. Do not use soap or harsh cleaning agents

LEGALESE

LIMITED PRODUCT WARRANTY

• For the latest and current terms of the Limited Product Warranty, please visit razer.com/warranty

LIMITATION OF LIABILITY

• Razer shall in no event be liable for any lost profits, loss of information or data, special, incidental, indirect, punitive or consequential or incidental damages, arising in any way out of distribution of, sale of, resale of, use of, or inability to use the Product. In no event shall Razer’s liability exceed the retail purchase price of the Product

GENERAL

• These terms shall be governed by and construed under the laws of the jurisdiction in which the product was purchased. If any term herein is held to be invalid or unenforceable, then such term (in so far as it is invalid or unenforceable) shall be given no effect and deemed to be excluded without invalidating any of the remaining terms. Razer reserves the right to amend any term at any time without notice.
